CS-116
2.3.1 IP Filtering
The IP filtering function keeps unauthorized hosts from accessing to the IP serial console by specifying IP filtering rules. It is
important to fully understand what an IP filter is. If you don’t fully understand this, you will get unexpected results against your
original plan.
The IP address/ Mask specifies the host range by entering base host IP address followed by / and subnet mask. The host IP
addresses to be filtered based on the rule defined. The table below gives examples of IP address/ Mask settings.
Specified host range Base Host IP address Subnet mask
Any host 0.0.0.0 0.0.0.0
192.168.1.120 192.168.1.120 255.255.255.255
192.168.1.1 ~ 192.168.1.254 192.168.1.0 255.255.255.0
192.168.0.1 ~ 192.168.255.254 192.168.0.0 255.255.0.0
192.168.1.1 ~ 192.168.1.126 192.168.1.0 255.255.255.128
192.168.1.129 ~ 192.168.1.254 192.168.1.128 255.255.255.128
The Port is a port or port range of the IP serial console which hosts try to access to.
Chain rule
The chain rule determines whether the access from the hosts is allowed or not. It can be one of the these two values :
■
ACCEPT : access allowed
■
DROP : access not allowed
When the IPCS receives a TCP packet, it will process the packet with the chain rule depicted below. The process ordering is
important; The packet will enter the chain rule 1 first, if meet the rule then take action directly, otherwise go to chain rule 2.
TCP packet
No
Rule 1
Rule 2
Rule ..
Rule n
Default Rule
Action 1
Yes
No
No
No
Action 2
Yes
Action 3
Action 4
Action 5
Yes
Yes
Yes
