CS-116
2.11.2 Upgrade from web page
If you want to run the new firmware, you need to click the Reboot item, then Yes to confirm to reboot the system. It will
take about one minute to finish the system reboot. When the IP serial console unit finishes the startup and working
normally, the Ready green LED will blink every second.
P.26
Warning :
A new firmware release version may need one, two, or up to three images to upgrade. You have to upgrade all to be
upgraded images before rebooting the system. Otherwise may cause inconsistency between kernel and application
firmware and the system may not be able to start up successfully. In this case, we have to upgrade through bootloader
process, which is not as friendly as the web method.
< 2.11 > Firmware Upgrade
