UM-CV-751-CS-116-Q215V1 www.austin-hughes.com

Console

P.2

< 1.2 > Connect to Single Serial Device or Headless Server

SG-100F

RJ45-DB9
female adapter

Cat5 cable

Computer with RS-232 serial port

Hub
Router
Switch

PDU
UPS
Power module

Serially
managed device

SG-100F

RJ45-DB9
female adapter

SG-100M

RJ45-DB9
male adapter

Cat5 cable

Cat5 cable

Cat5 cable

Network device
hub or router

Headless servers

CS-116

CS-116

Power

Optional Accessories

SG-100F

RJ45-DB9 female adapter

SG-100M

RJ45-DB9 male adapter

RJ45 Serial port
