- 32 -
Diagnostic Testing
ASCII Self-test
1.
Power on the printer while pressing the ONLINE key.
Pressing the ONLINE key a second time will stop printing. Reboot the
printer to exit ASCII test mode.
Print head pin test
1.
Power ON printer, load paper and then turn OFF the printer.
2.
Press the ONLINE and LOAD/EJECT keys while turning on the printer.
Hex dump mode
1.
Turn power on while pressing the LOAD/EJECT key to enter Hex Dump
mode. In this mode, the data sent from computer will print in
Hexadecimal code. Pressing the ONLINE key can stop printing, reboot
the printer to exit Hex Dump mode.
ASCII TEST MODE
AMT Documax 5380 VX.X XXX XXXX/XX/XX SN: XXXXXXXX
MAC: XX-XX-XX-XX-XX-XX DHCP: YES IP: 10.0.0.1 Subnet: 25
!"#$%&’( )*+-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`abc
!"#$%&'( )*+-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`abcd
"#$%&'( )*+-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`abcde
***** HEXADECIMAL DUMP *****
(0000) 1B 34 41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4E .4ABCDEFGHIJKLMN
(0010) 4F 50 51 52 53 54 55 56 57 58 59 5A 0D 0A 1B 35 OPQRSTUVWXYZ...5
(0020) 41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4E 4F 50 ABCDEFGHIJKLMNOP
(0030) 51 52 53 54 55 56 57 58 59 0D 0A QRSTUVWXYZ..
Starting this test without paper pre-
loaded will execute the Carriage Seek
test instead of Pin Test.
