- 11 -

Connecting the printer to the PC

Note: The Documax 5380 printer can use a USB, Ethernet, or Serial
cable to connect to the PC. Parallel interface is optional.

Install desired interface connection. Make sure that the power switch is
turned to OFF and connect the appropriate cable(s) to the printer and
the computer.

USB interface

USB cable

 Plug the USB cable A end (flat shape) into the computer's USB interface.
 Plug the USB cable B end (square shape) into the printer's USB interface.

USB CABLE CONNECTION

Ethernet cable

Ethernet interface

ETHERNET CABLE CONNECTION

 Plug one end of the RJ-45 cable into the Ethernet port of the printer and the

other into the LAN.

 Use NetFinder utility to identify IP address and help complete interface

connection.
