AMT Datasouth Fastmark 400 - Manual (Page 50)

User's Guide 49
Appendix A: Printer Specifications
Specification FM402DT FM402TT FM403TT
Print method Direct thermal Direct thermal and thermal transfer
Resolution 203 DPI
(8 dots/mm)
300 DPI
(12 dots/mm)
Maximum print
width 4.2 in. (107 mm) 4.10 in. (104 mm)
Maximum print
length 43 in. (1090 mm)
**
29 in. (736 mm)
**
Maximum print
speed 2 inches (50.8 mm)
per second
3 inches (76.2 mm)
per second
2 inches (50.8 mm)
per second
Onboard RAM 512 K bytes 2 M bytes
I. Direct thermal:
Paper, vinyl, visible light and infrared scannable label, tag
stock, butt cut or die cut, with various adhesives.
Media type
II. All above media, plus thermal transfer
paper or vinyl labels and tags, butt cut
or die cut, with various adhesives.
Maximum label
roll diameter 4 in.(102mm) outside diameter, 1 in.(25.4mm) inside
diameter
Label indexing Black stripe and gap
Ribbon types Wax, Wax/resin and Resin
Ribbon size OD 1.45 in. (37 mm); ID 0.5 in. (12.7mm)
Interface RS-232 serial and Centronics parallel ports, auto polling for
both ports
Dimension W7.3 in. x D10.9 in. x H6.0 in.
(W186 mm x D278 mm x H153mm)
Weight 1.7 kg (3.74 lbs.) 1.9 kg (4.1 lbs.)
FCC class B FCC class A Electrical
CE, UL and CUL approved. Input 19 VAC or 24 VDC
(min. 2.5 A), 50/60 Hz
Operating
temperature 40 ° to 140 ° F (5 ° to 38 ° C)
Storage
temperature -40 ° to 140 ° F (-40 ° to 60 ° C)
Humidity 15 to 85% RH
Windows driver Win, 95, 98, 2000 and NT
Rotation 0 o , 90 o , 180 o and 270 o , 4 direction rotations
