Introduction 3
RB-740
Table 1-1: ReadyBoard 740 General Specifications
Display
Chipset • GMA 3150 integrated in CPU
• BCM70015 H/W Video Decoder (H.264)
VGA • Dsub-15 connector, up to 2048x1536 (QXGA)
LVDS/DVI • Single channel 24-bit LVDS up to 1366 x 768
• DVI-D interface up to 1920 x 1080
• Optional 18-bit LVDS w/o DVI
Ethernet
Controller • Intel® 82574L PCIe network controller
• 10/100/1000BASE-T dual-Gigabit Ethernet
• Wake on LAN supported
Ports • 1x RJ-45 Ethernet port
Mechanical and Environment
Form Factor • EPIC size single board computer
Dimensions • 165.1 mm x 114.3 mm (L x W)
Board Thickness • 2.36 mm (0.093”)
Operating Temp. • Standard: 0°C to 60°C
• Extended: -20°C to 70°C
Storage Temp. • -20ºC to 75ºC
Rel. Humidity • 90% at 60°C
Shock • 50G peak-to-peak, 11ms duration, MIL-STD-202G
Method 213B, non-operating
Vibration • 11.95 Grms, 50-2000 Hz, each axis, MIL-STD-202G
Method 214A, operating
Certifications • CE, FCC Class A, EN-61373
