80

System Resources

12

PS/2 Mouse / PCI / ISA

IRQ12 via SERIRQ, IRQ12 at ISA

bus

13

Math Processor

N/A

14

SATA Controller 0

IRQ14 via SERIRQ, IRQ14 at ISA

bus

15

SATA Controller 1

IRQ15 via SERIRQ, IRQ15 at ISA

bus

16

USB Controller

N/A

17

INTEL AMT

N/A

18

Standard Dual Channel PCI IDE

Controller

N/A

19

N/A

N/A

20

N/A

N/A

21

N/A

N/A

22

High Definition Audio Contoller

N/A

23

USB Contoller

N/A

IRQ#

Typical Interrupt Resource

Connected to Pin

Table B-4: IRQ Lines APIC Mode
