18 Hardware Information
Table 2-1: M-342 Board Layout Legend
AAFP1 Front Panel Audio Header
ATX12V1 ATX 12V Power Connector
DIMM_A1/A2 240-pin DIMM slots (Channel A)
DIMM_B1/B2 240-pin DIMM slots (Channel B)
EATXPWR1 ATX Power Connector
CLCMOS Clear CMOS Jumper
COM1~6 Serial Port Connectors 1~6
CPU_FAN CPU Fan Connector
F_PANEL System Panel Pin Header
JLPC LPC Pin Header
JP1~3 COM6 Mode Jumpers
LPT1 Printer Port Connector
PCIEX4_1 PCI Express x4 slot
PCIEX16_1 PCI Express x16 slot
PCI1~5 PCI slots
PSON1 AT/ATX Mode Jumper
SATA1~2 SATA 6 Gb/s Connector
SATA3~6 SATA 3 Gb/s Connector
SPI SPI Pin Header
SYS _FAN System Fan Connector
USB56/78/910/1112 USB 2.0 Pin Headers
