Board Interfaces 35
cPCI-6615
CompactPCI J5 Pin Assignment
Table 4-21: CompactPCI J5 Connector Pin Definition
Pin Z A B C D E F
22 GND NC GBE2_LED_ACT-L +3.3V GBE1_LED_ACT-L +3.3V GND
21 GND LA_DATA_N2 LA_DATA_P2 GND LA_CLKN LA_CLKP GND
20 GND LA_DATA_N0 LA_DATA_P0 GND LA_DATA_N1 LA_DATA_P1 GND
19 GND NC NC NC NC NC GND
18 GND NC NC RTM_DETECT-L NC NC GND
17 GND NC NC REAR_GPIO8 NC NC GND
16 GND NC NC REAR_GPIO7 NC NC GND
15 GND NC NC REAR_GPIO6 NC NC GND
14 GND NC NC GND NC NC GND
13 GND GBE2_LED_100-L GBE1_LED_100-L NC GBE1_LED_1000-L GBE2_LED_1000-L GND
12 GND NC NC NC NC NC GND
11 GND NC NC GND NC NC GND
10 GND NC NC GND NC NC GND
9 GND ICH_GPIO12 ICH_GPIO13 ICH_GPIO14 ICH_GPIO22 ICH_GPIO39 GND
8 GND NC NC GND LDDC_CLK LDDC_DATA GND
7 GND GND GND CN_VCC_RTCR GND GND GND
6 GND NC NC GND NC NC GND
5 GND GND GND GND GND GND GND
4 GND NC NC GND NC NC GND
3 GND NC NC GND NC NC GND
2 GND NC NC GND NC NC GND
1 GND NC NC GND NC NC GND
Ethernet port
GPIO
LVDS
