Specifications
7
cPCI-6615
2
Specifications
2.1
cPCI-6615 Specifications
CompactPCI
Standards
• PICMG® 2.0 CompactPCI® Rev. 3.0
• PICMG® 2.1 Hot Swap Specification Rev.2.0\
• PICMG® 2.16 Packet Switch Backplane R1.0 (optional)
Mechanical
• Standard 6U CompactPCI®
• Board size: 233.33mm x 160mm
• Single-slot (4HP, 20.32mm); Dual-slot (8HP, 40.64mm) width
• CompactPCI® connectors with J1, J2 J3 and J5
Processor
• µFC-BGA dual-core Intel® Atom™ Processor D525
1.8 GHz, 1MB L2 cache, TDP 13W
• Passive heatsink
Chipset
• Intel® ICH8M I/O Controller Hub (ICH)
Memory
• Single channel DDR3-800 unbuffered non-ECC memory
• Two SODIMM Sockets
• Maximum up to 4GB capacity (dependent on memory
process technology)
BIOS
• AMIBIOS8® 16Mbit SPI flash memory
CompactPCI
Bus
• PCI 32bit/ 33MHz; 3.3V, 5V universal V(I/O)
• Supports operation in system slot only
Gigabit
Ethernet
• Three PCI-Express x1 Intel® 82583V Gigabit Ethernet
controllers
• Three egress 10/100/1000BASE-T ports and optional two
GbE ports switchable to J3 (RTM) by BIOS setting
Graphics
• Integrated in Intel® Atom™ Processor
• DB-15 VGA port on front panel for 8HP, switchable to J3
(RTM) by jumper setting
• Onboard VGA box header for 4HP version (routed to J3 by
default)
• Analog monitor support up to QXGA 2048x1536 @60Hz,
32-bit
• Single LVDS channel supporting resolution up to 1366x768
Serial Ports
• Up to four serial ports from Super I/O ITE8783
• One RS-232/422/485 on front panel for 4 HP and one
additional RS-232 on front for 8HP
• Two serial ports (RS-232) routed to J3
Storage
Interface
1
• CompactFlash Type II socket onboard (IDE)
• 2.5” SATA HDD connector onboard
BIOS
• AMIBIOS8® 64Mbit SPI flash memory
