Page 60: Sata drive
48
Getting Started
5.3
SATA Drive Installation
The cPCI-6520 provides space to install a slim type 2.5” SATA
drive.
Installing a
SATA Drive
- cPCI-6520
1. Locate the LB-LSATA daughter board in the package
and connect it to slim type 2.5"drive.
2. Find the drive bracket in the package and orient the drive
and bracket as shown below.
