10 Specifications
Gigabit
Ethernet • One front panel GbE LAN port from Intel® 82579LM PHY
controller and one front panel GbE LAN from Intel 82574
Gigabit Ethernet controller
• Two 10/100/1000BASE-T ports routed to J3 for PICMG
2.16
• Two additional 10/100/1000BASE-T ports from Intel®
82576EB Gigabit Ethernet controllers on RTM (cPCI-
R6100 or cPCI-R6110)
Serial Ports Up to three 16C550 serial ports
• One DB-9 RS-232/422/485 serial port on front panel
• Two serial ports routed to rear I/O through J3
USB 2.0 • Six USB 2.0 ports routed to J3
USB 3.0 • Three USB 3.0 ports on front panel, one to J5
KB/MS • PS/2 Keyboard/Mouse port to J3
Audio • High Definition Audio signals routed to J3
TPM Atmel AT97SC3204 TPM (upon request)
• Over/Under voltage detection
• Low/High frequency sensor/filter
• Reset filter
• Memory Encryption/Decryption
Storage
Interfaces
1
• One SATA 6 Gb/s direct connector for 2.5" onboard drive
(removable)
1
• Optional CompactFlash socket onboard
• Optional CFast socket onboard via DB-CFAST adapter
board (shares space with 2.5" SATA drive)
• One onboard 7-pin SATA connector
BIOS • AMI EFI BIOS, 64Mbit SPI flash memory
Faceplate I/O • 2x 10/100/1000BASE-T Ethernet ports
• 2x DisplayPorts
• 3x USB 3.0 ports
• 1x RJ-45 RS-232/422/485 port
• PMC/XMC slot
OS
Compatibility • Microsoft Windows 7 32/64-bit
• Microsoft Windows 2008 Server 32-bit, R2 64-bit
• Red Hat Enterprise Linux 6.2 x86 64-bit
• Fedora 16 x86 64-bit
• Wind River VxWorks 6.9 BSP
• Other OS support on request
Table 2-1: cPCI-6520 Blade Specifications
