Introduction 3
cPCI-6520
1.2 Features
X 6U CompactPCI® processor blade in 4HP width form factor
X Supports FCBGA package 4-core 3rd Generation Intel®
Core™ i7-3615QE 2.3GHz, 6MB L3 Cache, 45W TDP
X Mobile Intel® QM77 Express Chipset (Intel® BD82QM77
PCH)
X Dual channel DDR3-1066/1333/1600 ECC SDRAM up to
16GB, one channel soldered up to 8GB, one channel
SO-CDIMM up to 8GB
X 32/64-bit, 33/66MHz CompactPCI® Interface based on PCI
specifications, universal V(I/O)
X Supports Satellite Mode operation as a standalone blade in
peripheral slots
X One 32/64-bit, 33/66/133MHz PMC or PCI Express x8 XMC
site
X Three USB 3.0 ports on front panel
X SATA 6 Gb/s direct connector for onboard 2.5" drive
X Onboard CompactFlash socket
X Optional CFast support (shares space with 2.5" SATA drive)
X Eight general purpose user programmable LEDs on front
panel (default: Port 80 status)
X Up to three independent displays from front panel Display-
Ports (DVI, VGA, HDMI output by adapter cables) and DVI,
eDP and VGA routed to rear I/O*
X Two Gigabit Ethernet ports on front panel supported by
Intel® 82574L and Intel® 82579LM Ethernet controllers
X Compliant with PICMG 2.0, 2.1, 2.9, 2.16 standards
X Atmel AT97SC3204 TPM support (upon request)
NOTE: NOTE:
*If one of the front panel DisplayPorts is converted to DVI or
HDMI, the cPCI-6520 can support only two independent dis-
plays via the front panel and the rear I/O display output is dis-
abled.
