ADLINK PCI-9820 User Manual
Page 6
ii
• Table of Content
s
4.4
Trigger Sources ..................................................................24
4.4.1
Software-Trigger ............................................................. 24
4.4.2
External Analog Trigger .................................................. 24
4.4.3
External Digital Trigger ................................................... 25
4.5
Data Transfers....................................................................26
4.6
AI Data Format ...................................................................27
4.7
Synchronizing Multiple Devices..........................................28
4.7.1
SSI_TIMEBASE.............................................................. 28
4.7.2
SSI_TRIG1 ..................................................................... 28
4.7.3
SSI_TRIG2 and SSI_START_OP................................... 29
4.7.4
Comparing the different trigger sources from SSI........... 30
4.8
Auto-calibration...................................................................31
Warranty Policy........................................................... 33
