Introduction
• 3
1.1 Features
• Supports 32-bit 3.3V or 5V PCI bus
• 14-bit A/D resolution
• Up to 60MS/s sampling rate per channel with internal timebase
• Up to 65MS/s sampling rate per channel with external timebase
• Up to 130MS/s sampling rate using “ping pong” mode for sin-
gle-channel acquisition
• 2-CH simultaneous-sampled single-ended analog inputs
• Programmable input ranges of ±1V and ±5V
• User-selectable input impedance of 50Ω or high input impedance
• >30MHz -3dB bandwidth
• Up to 512MB on-board SODIMM SDRAM
• Scatter-gather DMA data transfers
• Analog and digital triggering
• Fully auto calibration
• Multiple cards synchronization
• Compact, half-size PCB
1.2 Applications
• Communication system analysis
• Software radio
• Automotive Testing
• RF signal analysis
• Transient signal capture
• ATE
• Laboratory automation
• Biotech measurement
