• Introduction
• Analog triggering
Sources: CH0 and CH1
Slope: rising/falling
Coupling: DC
Trigger sensitivity: 256 steps in full-scale voltage range
Hysteresis: 1.5% of the full range
Offset error: 1.25% of the full range
• Digital triggering
Connectors: SMB
Slope: rising/falling
Compatibility: 5V/TTL
Minimum pulse width: 10ns
♦ Calibration
• Recommended warm-up time: 15 minutes
• On-board calibration reference:
Level: 5.000V
Temperature coefficient: ±2ppm/°C
Long-term stability: 6ppm/1000Hr
♦ General Specifications
• Dimensions: (not including connectors)
175mm by 107mm
• I/O connector:
BNC x 2 for analog inputs
SMB x 2 for external timebase and external digital trigger
• PCI signaling environment:
Universal board, supports a 32-bit 3.3V or 5V PCI bus
• Operating environment:
