22

Registers Format

3.5 Mode and Interrupt Control Register

The Mode and Interrupt control register is a write-only register. This register
control the AD operating modes and the IRQ level of the ACL-8111. The AD
operation modes include the AD clock source and the AD data transfer
method.

Address: BASE + 11

Attribute: write only

Data Format:

Bit

7

6

5

4

3

2

1

0

BASE+11 X IR2 IR1 IR0 X M2 M1 M0

Where M0, M1, and M2 are mode selection:

M2

M1

M0

Description

0

0

0

Software trigger with program polling

0

0

1 (No interrupt generated)

0

1

0

External trigger with program polling

0

1

1

External trigger with interrupt polling
(With End-of-conversion “EOC” interrupt)

1 0 0

Internal time pacer trigger and polling
(No interrupt generating)

1 0 1

Not

Used

1 1 0

Internal timer pacer trigger with interrupt data
transfer(With End-of-conversion “EOC” interrupt)

1

1

1

Not Used

Note: The external trigger signal comes from the DI 0 (pin-1 of CN2).

Where IR0, IR1, and IR2 are interrupt IRQ level settings:

IR2

IR1

IR0

IRQ Level

0 0 0

IRQ2

0 0 1 Not

Used

0 1 0

IRQ2

0 1 1

IRQ3

1 0 0

IRQ4

1 0 1

IRQ5

1 1 0

IRQ6

1 1 1

IRQ7
