24 Signal Connections
*PIO means programmable I/O
35~38 CH<0..3>- -------- Input
Differential negative
input for AI channel
<0..3>
39 AIGND -------- -------- Analog ground for AI
40~42 AOGND -------- -------- Analog ground for AO
43~46
SDI<3..0>_0 (2010)
NC (2005/2006/2016)
DGND Input
Synchronous digital
inputs
47 EXTWFTRIG DGND Input
External AO wave-
form
trigger
48 EXTDTRIG DGND Input
External AI digital
trigger
55 AFI0 DGND Input
Auxiliary Function
Input 0 (ADCONV,
AD_START)
21 AFI1 DGND Input
Auxiliary Function
Input 1 (DAWR,
DA_START)
Pin # Signal Name Reference Direction Description
Table 3-2: VHDCI-type (68-pin) Connector Legend
