22 Signal Connections
VHDCI-type (68-pin) Connector
*SDI for DAQ/DAQe/PXI-2010 only. NC for DAQ/DAQe/PXI-2005/
CH0+ 1 35 CH0-
CH1+ 2 36 CH1-
CH2+ 3 37 CH2-
CH3+ 4 38 CH3-
EXTATRIG 5 39 AIGND
DA1OUT 6 40 AOGND
DA0OUT 7 41 AOGND
AOEXTREF 8 42 AOGND
SDI3_1 / NC* 9 43 SDI3_0 / NC*
SDI2_1 / NC* 10 44 SDI2_0 / NC*
SDI1_1 / NC* 11 45 SDI1_0 / NC*
SDI0_1 / NC* 12 46 SDI0_0 / NC*
AO_TRIG_OUT 13 47 EXTWFTRG
AI_TRIG_OUT 14 48 EXTDTRIG
GPTC1_SRC 15 49 DGND
GPTC0_SRC 16 50 DGND
GPTC0_GATE 17 51 GPTC1_GATE
GPTC0_OUT 18 52 GPTC1_OUT
GPTC0_UPDOWN 19 53 GPTC1_UPDOWN
EXTTIMEBASE 20 54 DGND
AFI1 21 55 AFI0
PB7 22 56 PB6
PB5 23 57 PB4
PB3 24 58 PB2
PB1 25 59 PB0
PC7 26 60 PC6
PC5 27 61 PC4
DGND 28 62 DGND
PC3 29 63 PC2
PC1 30 64 PC0
PA7 31 65 PA6
PA5 32 66 PA4
PA3 33 67 PA2
PA1 34 68 PA0
Table 3-1: VHDCI-type (68-pin) Connector Pin Assignment
