step 10

Hood/trunk pins

The BLUE (H1/6) wire will respond to a negative input with an

instant trigger. It is ideal for hood and trunk pins and will report

on Zone 1. It can also be used with Directed Electronics 506T

Glass Breakage Sensor, as well as other Directed Electronics

single stage sensors.

step 11

Adjusting the shock sensor

The double guard shock sensor is a two stage sensor; with both

warn away trigger and full trigger zones. Adjustment of the

sensor will affect both zones simultaneously. To adjust the sensor,

turn the adjustment screw on the side of the control module.

■

For a more sensitive setting turn the adjustment screw clockwise

in small increments, testing the sensitivity after each adjustment

until the desired setting is achieved.

■

For a less setting turn the adjustment screw counter clockwise in

small increments, testing the sensor after each adjustment until

the desired setting is achieved.

iim

poorrttaan

ntt:: Ensure that the adjustment screw on the con-

trol module is accessible in the permanent location.

noottee:: The control module must be mounted in its per-
manent location before adjustments are made.

➜
