LCP-10G3B4EDR
DELTA ELECTRONICS, INC.
4 Revision: 0B
2008/9/5
www.deltaww.com
Figure 1. 10GBASE-LRM Transmitter spectral limits
Optical Receive Characteristics (T
c
= -5 to 70 )
Parameter Symbol Min. Typ. Max. Unit Note
Signaling speed (nominal) T
S
10.3125 Gb/s
Signaling speed variation from
nominal.
±100 ppm
Center Wavelength λ 1260 1355 nm
Overload in OMA P
O
1.5 dBm
Stressed sensitivity in OMA RSO -6.5 dBm 1
Stressed sensitivity in OMA for
symmetrical test
-6 1
LOS De-assert LOS
D
-14.5 dBm
LOS Assert LOS
A
-22 dBm 2
LOS Hysteresis LOS
D
-LOS
A
0.5 dB
Notes:
1. PRBS
2 31 -1 at 10 -12 BER
2. When LOS asserted, the data output is Low-Level (fixed)
