LCP-10G3B4EDR
DELTA ELECTRONICS, INC.
1 Revision: 0B
2008/9/5
www.deltaww.com
10GBASE-LRM SFP+ Optical Transceiver Preliminary
FEATURES
RoHS compliant
Compliant to SFP+ Electrical MSA SFF-8431
Compliant with SFF-8472 MSA
Standard LC duplex fiber-optic connector
I 2
C for integrated Digital Optical Monitoring
Power consumption 1W
Description
The LCP-10G3B4EDR is a hot pluggable
10Gbps small form factor plus transceiver
module integrated with the high performance
1310nm FP Laser transmitter, high sensitivity
linear PD-TIA receiver for 10Gbps applications.
It is compliant with the SFF-8431 SFP+
Electrical Multi-source Agreement (MSA) with
five digital monitoring functions: Temperature,
Vcc, Tx optical power, Tx laser bias current and
Rx received optical power.
Applications
10G LAN switch
10G Ethernet switch/router
10G Fiber channel
SAN applications
