RCX SYSTEM OPTIONS
1 DOOR STATIONS
— To receive a call from up to two door stations at either of up to five programmed master stations;
(1) A call from door station is announced at all programmed master stations by electronic chime.
* If the chime is 4 strokes, the call is from the First door station.
Press [ a ] H buttons.
* If the chime is 2 strokes, the call is from the second door station.
Press Q buttons.
(2) Talk handsfree. In RA-A, Pick up the unit and hold the bar switch and, in RA-D, pick up handset for private hand­
set communication. When the door station is situated in a noisy area, you may press (T] (TALK) button to talk and
release to listen.
(3) If your system includes a door release, momentarily press button during communication, which activates the
timer circuits for opening the door.
(4) Press (OFF) button or hang up handset in RA-D to end communication with door station.
2 ADDITIONAL PAGING/REMOTE CONTROL
To select any YAW adaptor, press [yj 0 buttons.
(1) When continuous mono tone is heard;
Paging with YAW-R or YAW-RA;
Press Q4] button and an adaptor number button (0 ~ 9) (and a zone number button in YAW-RA 1 ~ 8). Make announcement
depressing button (and release to listen, if talkback is included). Press button at end of announcement.
NOTE:
After selecting an adaptor number for YAW-RA, press zone number buttons (1 ~ 8) in succession for multiple zone page or
r^i button for all page (to 8 zones simultaneously).
Remote operation of controlling ON/OFF of lights or door release, etc.;
Press button and an adaptor number button (0 ~ 9) for YAW-S.
* When an intermittent tone is heard, the lighting function is in ON mode.
* When a continuous tone is heard, the lighting function is in OFF mode.
Alternate operation: Momentarily press H button to turn on lights. OR
Momentarily press [jT] button to turn off lights.
Momentary operation: Press and hold button down to activate door release, etc.
Press button.
(2) When intermittent tone is heard;
It means other station is operating paging or remote control and the channel is occupied. Press H button to disconnect and call
later.
NOTES:
1. It is not possible to operate two or more adaptors at the same time.
2. Paging/remote control operations can be made by master stations RA-A, RA-B and RA-D.
- 7 -
