Fig. 2 — Model Number Nomenclature
Fig. 3 — Serial Number Nomenclature
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
3 8 A U Z A 0 4 A 0 G 6 – 0 A 0 A 0
_____________ ____
Model Type Packaging
38AU= Carrier Condensing Unit
Puron r R---410A Refrigerant
0 = Standard
Type of Coil
Electrical Options
Z = Single Circuit, A/C Scroll Compressor
A = None
C = Non-Fused Disconnect
1 = LTL
Service Options
0 = None
1 = Un-powered Convenience Outlet
Nominal Tonnage
1 =
07 = 6 Tons
08 = 7.5 Tons Not Used
12 = 10 Tons A = Place Holder
14 = 12.5 Tons
Base Unit Controls
0 = Electro-Mechanical Controls Not Used
A = Not Used
Design Rev
--- = Catalog Model Number
Voltage
1 = 575/3/60
5 = 208/ 230/3/60
6 = 460/3/60
Refrigerant Options
A = None
B = Low Ambient
Not Used
0 = Not Used
Coil Options
G = Al/Al
2 = Powered Convenience Outlet
S E T A N G I S E D N O I T I S O P
) r a d n e l a c l a c s i f ( e r u t c a f u n a m f o k e e W 1−2
) A S U , s a x e T , P T E = G ( n o i t a c o l g n i r u t c a f u n a M 5
r e b m u n l a i t n e u q e S 6−10
1 2 3 4 5 6 7 8 9 10
4 8 0 8 G 1 2 3 4 5
POSITION NUMBER
TYPICAL
Year of manufacture (”08” = 2008) 3−4
