Fig. 1 — 38AUZ*07-14 Unit Dimensions
UNIT
Standard
Weight
Corner
A
Corner
B
Corner
C
Corner
D
Center of Gravity Unit Height
lbs. kg. lbs. kg. lbs. kg. lbs. kg. lbs. kg. X Y Z H
38AUZ*07 328 149 128 58 68 31 62 28 70 32
21.00
[533.4]
19.00
[482.6]
13.00
[330.2]
42.36
[1076.0]
38AUZ*08 353 160 138 63 72 33 65 29 78 35
19.00
[482.6]
23.00
[584.2]
13.00
[330.2]
42.36
[1076.0]
38AUZ*12 418 190 165 75 85 39 78 35 90 41
23.00
[584.2]
20.00
[508.0]
15.00
[381.0]
50.36
[1279.2]
38AUZ*14 431 196 162 73 82 37 92 42 95 43
19.00
[482.6]
23.00
[584.2]
15.00
[381.0]
50.36
[1279.2]
