M c -d, O alphone video door station, Model: v
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".

830313
0788
O AlPHONE
VIDEO DOOR STATION
MODEL:
V_________________________
M C -D
Door station with
CCD camera,
surface-mount
J
INSTALLATION MANUAL
25.5 mm
T
20.5 mm (3/4")
38 mm
134
mm
92
mm
(5-1/4")
(3-5/8”)
20.5 mm
13/4”)
SIDE VIEW
NAMES AND FUNCTIONS
© CCD
camera
@ Speaker
® Microphone
® Location indicator LED (red)
(§)
Infrared LEDs
® Camera ON indicator LED (green)
@ Directory card
® CALL button
Terminal section
a
FEATURES
MC-D is a video door station for use with MC-U/MCH-U video monitor and IC-series Chime Tone Intercom: either IC-1 AD(U),
IC-1GD(U)/A or IC-2AD(U)/Aor TD-H selective call intercom system.
MC-D can be used as a surveillance camera, using MCW-P3, 3-camera adaptor (with video monitoring capability for up to 3
locations). Can be installed max. one MC-D & two surveillance cameras for MCW-P3/IC-1GD(U)/A system, and max. two
MC-D and one surveillance camera for MCW-P3/IC-2AD(U)/A system.
Employs
CCD
(Charge-coupled device) camera, featuring;
1. almost permanent life of camera unit,
6.
no after-image created.
2. no possibility of being damaged by strong light.
7.
picture less distorted, as not so affected by magnetic and
3. more compact and lighter weight.
electrostatic field.
4. low current circuitry.
8.
auto-iris sensitivity adjustment.
5. clear picture by higher resolution,
9.
maintenance-free, as periodical replacement of vidicon has
been eliminated.
Weather-resistant type.
Camera lens is protected by vandal-resistant shield. Front panel is of anodized aluminum with tamper-proof screw.
The camera has wide-angle lens, capturing image from 25 cm to 5 m (10" to 16')-
Either semi-flush or surface mounting (MCW-R surface mounting box supplied by AlPHONE).
Simple wiring. One coaxial cable plus single pair.
MAW-B relay box for auxiliary light to illuminate the caller from the front (to improve backlight phenomenon).
-
1
-
