Installation Instructions
A CAUTION A
Because the compressor is located oh the
controls side of the unit (right |ide),. this side
will be heavier and more awkward to rriahipulate.
Inadequate support on control side ht th!? unit
can result in personal injury and damage to your
unit and property Therefore, it is recommended
to have someone assist you during the installation
of this unit
F Your Bryant unit was designed to evaporate
condensation under nottrial conditions However,
under extreme humidity conditions, excess
condensation may cause basepah to overflow to
the outside. The unit should be Installed where
condensation run-off cannpt drip pn pedestrians
or neighboring properties
G A drain connection(excluding hose) is provided
If you need to redirect condensation overflow, see
{Fig 19 0T\Page11)
Select the Best Location
A Your Bryant Room Air Conditioner was designed to
fit easily into a single or double hung window However,
since window designs vary, it may be necessary
to make some modifications for safe and proper
installation
B Make sure window and frame is structurally
sound and free from dry and rotted wood
C For maximum efficiency, install the air conditioner
on side of the house or building which favors more
shade than sunlight. If the unit is in direct sunlight,
it is advisable to provide an awning over the unit
D Provide sufficient clearance around the cabinet
to allow for ample air circulation through the unit
See (Dwg 1) The rear of the unit should be outdoors
and not in a garage nor inside of a building
Keep unit as far away as possible from obstacles or
obstructions and at least 30" above the floor or ground.
Curtains and other objects within a room should be
prevented from blocking the air flow
E Be certain the proper electrical outlet is within reach
of the installation Use only a single outlet circuit rated
at 15 amps All wiring should be in accordance with local
and national electrical codes
Side
obstruction
Fence,
wall, or
other
obstacle
