Electrical Specifications
1. All wiring must comply with local and national
electrical codes and must be installed by a
qualified electrician if you have any questions
regarding the following instmctions, contact a
qualified electrician
2 Check available power supply and resolve any
wiring problems BEFORE installing and operating
this unit
3 This 115V air conditioner uses 12 0 or less
nameplate amps and may be used in any
properly wired, general purpose household
receptacle See {Tabte 1) for specifications for
individual branch circuit
4 For your safety and protection This unit is
grounded through the power cord when
plugged into a matching wall outlet If you are
not sure whether your wall outlet is properly
grounded, please consult a qualified electrician
$ggg^sted Individual Branch Circuit
. ^ : Nameplate Amps AWG Wire Size*
5.0 to 12 14
Avy(^ i^erican Wire Gage
* BaSed^on copper wire at 60 °G temperature rating.
Table 1
Receptacle and Fuse Types
Rated Volts 125
AMPS 15
Wall Outlet
w
Fuse Size 15
Time Delay Fuse
(or circuit breaker}
Plug type
Table 2
5 The wall outlet(3-pin) must match the plug
(3-pin) on the service cord supplied with the unit
DO NOT use plug adapters or extension cord.
See {Table 2) for receptacle and fuse information
6 The rating plate on the unit contains electrical
and other technical data The rating plate is located
on the right side of the unit, above the power cord
If missing, a second nameplate is located on front
chassis (also known as basepan)
Electric Shock Hazard
To avoid the possibility of personal
injury, disconnect power to the unit
I before installing or servicing
