Installation Instructions
7. instaflation of the cabinet
(Model 463AAC010BA and 463AAC012BA)
A Place the air conditioner cabinet in the window
Align ohe hole in the bottom of the cabinet with one
hole in the bracket assembly Secure the cabinet to
the brabket using a 1/4” screw provided Repeat
the same procedure on the opposite side of the
cabinet
{Fig 14)
B Ensure the "L” shaped mounting channel is
positioned in front of the sash The "U" shaped
channel on the bottom of the cabinet should be
positioned in the track provided on the bracket
assembly Pull the window down until it rests just
behind the front of the "L" shaped mounting channel
SeefF/g
IS).
C Check to make sure that the cabinet is slanted
slightly downward on the outside
-
10
-
