Introduction
Thank you for choosing this Bryant Room Air Conditioner to coo) your home This USE AND CARE
M anual provides information necessary for the proper care and maintenance of your new Rppm Air
Conditioner If properly maintained, your atf conditioner yyitl give you many years of trouble free operation'
To avoid installation difficulties, read instructions cdrhpletely before starting This manual contaihs ‘ '
information for the installation and operation of your^^ryant Room Air Conditioner
For easy reference, you may want to attach a copy of your sales receipt to this page Note following
information provided (on the manufacturer's nameplate located on the nght side of the unit above the power
cord) This information will be needed when you contact a Bryant's Customer Service Representative
Model number
Serial number
Date of Purchase
Dealer’s Name and Address
Refer to the trouble-shooting section of this USE AND CARE MANUAL if the unit is not operating correi
If these suggestions do not solve the problem, contact an authorized service representative or call |
1-800-428-4326
Keep these instructions for future reference
This symbol denotes a caution or warning
Specifications*
Model number
Unit Specifications*
463AAC010BA 463AAC012BA
Voltage 115V/60HZ 115V/60HZ
Cooling Capacity(Btu/h) 10,000 12,000
Input Wattage 1020 1220
Energy Efficiency Rating (EER) 98 9 8
Fan/Cooling Speeds 2/2 2/2
Cooling Area Coverage (Sq ft) 500 700
Noise Level (dB) 50 52
Unit Dimensions Width 20 5" 22 8""
Depth 23 0" 28 0"
Height 14 8" 15 7"
Window Kit Dimensions Maximum Width 37 8" 40 2"
Minimum Width 25 2"________ ___________ 27 6"
Height 15 7" 16 7"
Shipping Weight 1121b 120lb
NOTE Specifications are subject to change without further notice
~
3
-
