Installation Instructions
B Measure the inside window sill width and find the
center as shown in
{Fig 11) Align the Vfsldt in each
bracket on these marks and mount thé ibrackets tp
the sill using (4)
3/4” screws Brackets should bp
perpendicular to the inside window silli see
(Fig. 12).
C For proper condensation run-off it will be necessary
to adjust the angle of the window brackets
This Is accomplished by adjusting the leveling screw
on the outer wall The maximum angle should not
exceed more than 3/16" See
(Fig 12)
D Cut the
first foam sealing strip to fit the
underside of the bottom
widow sash Remove
the peel-off backing on the foam and attach it
to this sash
See (Fig 13)
V-sJot
A
CAUTION
A
If additional support to the bracket assembly is
required, use a solid piece of wood to provide
stability. This will be required when sills are
extra deep See (Fig. 10).
