OPERATIONS
The red LED is lit to locate call button, day or night. A single push of Call button activates inside video monitor, as well as a 4 or
2-tone chime (or other). When inside station replies, talk handsfree.
Poor lighting conditions:
The MY-DC/A and MY-DG/A's infrared illuminafion will light the image of the caller when positioned within 50cm, 20" in front of
the camera, and will see in near darkness (1 Lux of light).
TECHNICAL PRECAUTIONS
MY-DC/A and MY-DG/A do not have a camera angle
presetting feature.
■ installation location:
The MY-DC/A and MY-DG/A are weather resistant, but for
best results it should be protected from direct weather
conditions. An eave or overhead cover is recommended to
protect it from direct rainfall.
Temperature:
The MY-DC/A or MY-DG/A is rated to operate at
temperatures between -10° and 60°C (14° and 140°F).
When the outside temperature lowers rapidly, the camera
lens may fog up slightly, causing a blurry picture at the inside
monitor. The ventilation openings will allow the moisture to
evaporate, and the picture will return to normal.
Cleaning:
Clean the unit with a soft cloth and neutral household
cleanser. Do not use an abrasive cleaner or cloth.
a SPECIFICATIONS
Power source
Camera unit
Scanning iines
image viewing area
Minimum iliumination
Dimensions & weight
Camera is powered from monitor unit
CCD camera
525 lines
at 50 cm, 20" in front of camera
Vertical 90cm, 3'. Horizontal 180cm, £
when panned and tilted fully
1 Lux at 50cm, 20" from camera
H W D Weight approx.
MY-DC/A
190 120 36 (mm) 500g
7-1/2' A-m" 1-1/2" 1.10 lbs.
MY-DG/A
200 120 37 (mm) 560g
8" 4-3/4" 1-1/2“ 1.23 lbs.
*Both 33mm,1-1/4'recessed
Pan/tilt viewing area shown by dotted iine
130cm
{4’3”)
Camera
center
12cm (5”)
29cm (11”)
-200cm (67")
-171cm (5^8”)
90cm (3')
-122cm (4)
-110cm (3’81
MY-DC/A,
MY-DG/A
122 °
,57cm (22”)i 66cm (26”) i57cm (22”)
^--------------- ^180cm (6’) ^-------------
0cm
50cm
( 20 ”)
0cm 50cm (20”)
: Viewing area of camera in still position.
All figures are approximate.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur In a particular installation. If this equipment does cause harmful inteference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Increase the separation between the equipment and receiver. • Consult the dealer or an experienced radio/TV technician for help.
•Н*
•Н-
♦ ■*: ♦ ^
WARRANTY
Aiphone warrants its products to be free from defects of material and workmanship under normal use and service for a period of two
years after delivery to the ultimate user and will repair free of charge or replace at no charge, should it become defective upon which
examination shall disclose to be defective and under warranty. Aiphone reserves unto itself the sole right to make the final decision
whether there is a defect in materials and/or workmanship; and whether or not the product is within the warranty.
This warranty shall not apply to any Aiphone product which has been subject to misuse, neglect, accident, or to use in violation of
instructions furnished, nor extended to units which have been repaired or altered outside of the factory. This warranty does not cover
batteries or damage caused by batteries used in connection with the product.
This warranty covers bench repairs only, and any repairs must be made at the shop or place designated in writing by Aiphone.
Aiphone will not be responsible for any costs incurred involving on site service calls.
♦
•i-
-Í*
Aiphone Co., Ltd., Nagoya, Japan
Aiphone Corporation, Bellevue, WA, USA
W1Y-DC/A-I(E) 0995D
-
