Model 336
PARTS LIST FOR MODEL 336 ROTARY MOWER
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
718-0145
Plastic Grip Shrink Type
45
734-0538
Wheel Ass’y. Comp. 8 x 1.75
2
711-0570
Ferrule
47
738-0102
Shid. Bolt .498 Dia. x 1.44"
4
746-0315
Throttle Control Ass’y.
Lg.
Comp.
48
741-0262
Fortiflex Bearing
5
710-0606
Hex Bolt V4-20
X
1.50 Lg.*
49
712-0375
Hex Cent. L-Nut 3/8-16
7
710-0405
Curved Carriage Bolt
Thd.*
5/16-18
X
1.75 Lg.
50
736-0255
Bell-Wash. .51 I.D. x 1.12
8
726-0188
Cable Ties
O.D.
9
747-0267
Engagement Rod
51
10619
Pivot Bar
10
714-0150
Ferrule Locking Ring
52
738-0269
ShId. Bolt
19
—
Engine B & S 3.5 H.P.
53
12323
Index Plate
20
710-0776
Hex Wash. Hd. Self-Tap Scr.
54
14514
Rear Deck Section Ass’y.
1/4-20
X
.62" Lg.
55
712-0344
Speed Nut #10Z
21
12982
—456 Cover
56
710-0436
Hex B-Tap Scr. #10 x .62"
22
14510
—456 20" Rear Discharge S.P.
Lg.
Deck
57
710-0436
Hex B-Tap Scr. #10Z x .62"
23
712-0798
Hex Nut 3/8-16 Thd.*
Lg.
24
736-0169
L-Wash. 3/8 I.D.*
58
735-0639
Spark Plug Boot
25
12190
—456 Rear Discharge Baffle
59
710-0654
Hex Wash Hd. Tap Scr.
26
736-0329
L-Wash. 1/4 I.D.*
3/8-16
X
.88" Lg.
27
712-0287
Hex Nut 1/4-20 Thd.*
60
710-0167
Carr. Bolt 1/4-20
X
.50" Lg.*
28
742-0123
20" Blade
63
736-0329
L-Wash. 1/4" I.D.*
29
736-0217
L-Wash. 3/8 I.D.*
64
712-0287
Hex Nut 1/4-20 Thd.*
30
710-0459
Hex Bolt 3/8-24 x 1.50" Lg.*
66
710-0781
Hex Wash. Hd. Self-Tap Scr.
31
10769
Blade Adapter Kit
3/8-16
X
.88" Lg.
32
736-0119
L-Wash. 5/16" I.D.*
67
12321
Height Adjustment Ass’y.—
33
10769
Blade Adapter Kit
LH.
34
712-0123
Hex Nut 5/16-24 Thd.*
68
710-0289
Hex Bolt 1/4-20
X
.500" Lg.*
35
710-0117
Hex Bolt 5/16-24 x 1.00" Lg.
69
736-0329
L-Wash. 1/4" I.D.*
36
714-0365
#6 Hi-Pro Key 5/32" x 5/8"
70
14159
Handle Brkt. Ass’y.
Dia.
71
736-0329
L-Wash. 1/4" I.D.*
37
710-0167
Carr. Bolt 1/4-20
X
.50" Lg.*
72
712-0287
Hex Nut 1/4-20 Thd.*
38
726-0139
Speed Nut—U Type
73
14158
Handle Brkt. Ass’y.
39
710-0599
Hex Wash. Hd. Self-Tap Scr.
74
714-0104
Int. Cotter Pin .516 Dia.*
1/4-20
X
.50" Lg.*
75
749-0395
Lower Handle
40
710-0294
Hex Bolt 1/4-20
X
.375" Lg.*
76
749-0380
Upper Handle
41
12302
Side Plate
77
712-0107
Hex Cent. L-Nut V4-20 Thd.
42
710-0209
Hex Sems Bolt 3/8-16 x .62"
78
726-0134
Speed Nut #8-32
Lg.*
79
09966
Knob Handle Ass’y.
43
10530
Spring Lever Ass’y.
82
12322
Height Adjustment Ass’y.—
44
736-0105
Bell-Wash. .40 I.D. x .88
R.H.
O.D.
‘For faster service obtain standard nuts, boits and washers
iocaliy. If these items cannot be obtained localiy, order by
part number and size as shown on parts iist.
(456—Radiant Tangerine)
When ordering parts, if coior or finish is important, use the ap
propriate color code shown above, (e.g. Radiant Tangerine
Finish—12982 (456).)
NOTE: The engine is not under warranty by
the
mower
manufacturer...If
repairs
or
service is needed on the engine, piease
contact your nearest author-
——
ized engine service outlet. Find It Fast
Check the “Yellow Pages” of In The
your telephone book under Y^ow Pages
“Engines—Gasoline.”
NOTE
This instruction manual covers various models
and all specifications shown do not necessari
ly apply to your model. Specifications subject
to change without notice or obligation.
