APPENDIX
Bottom
■
USB Cradle
Front
Back
bs Battery/Memory Card Slots (pages 23, 34)
bt Cradle Contact (page 25)
ck Tripod Hole
Use this hole when attaching to a tripod.
cl Speaker (page 127)
bt ck cl bs
1 Camera Contact (page 25)
2 USB Lamp
(pages 198, 211, 234)
3 [USB] Button
(pages 187, 198, 211)
4 [PHOTO] Button
(pages 133, 134)
5 [CHARGE] Lamp
(pages 25, 234)
6 [AV OUT] (AV output port)
(page 134)
7 [ ] (USB) Connector
(pages 185, 197, 210)
8 [DC IN] (External Power)
Terminal (pages 24, 196, 209)
5
1
2
3
4
6
8
7
