CONTROLS
THROTTLE CONTROL
The throttle control is located on the left side of
the handle. It is used to regulate the engine speed
and to stop the engine. See figure 14.
FIGURE 14.
CLUTCH CONTROL
Squeezing the clutch control engages the drive
mechanism to the rear wheels. Releasing the
clutch control stops the rear wheels from driving.
Release the clutch control to slow down when
negotiating an obstacle, making a turn or stop
ping. See figures 14, 15 and 16.
Clutch
Control
Engaged
FIGURE 15.
FIGURE 16.
^ WARNING
\
The blade continues to rotate when
the clutch is released.
