PARTS LIST FOR MODEL 120-337A AND 120-337-300
REF.
l,NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 718-0145 Grip 40 738-0102 ShId. Bolt
2 712-0107 Hex Cent. L-Nut V4-20 Thd. 41 712-0375 Hex Cent. L-Nut 3/8-16 Thd.
3 746-0179 Throttle Control Ass’y. 42 736-0255 Belleville Wash. .50" I.D. x
Comp. 1.14" O.D.
X
.029
4 710-0606 Hex Bolt 1/4-20
X
1.50" Lg.* 43 10619 Pivot Bar
5 710-0405 Curved Hd. Carriage Bolt 44 10531 Spring Lever Ass’y. w/Knob
5/16-18
X
1.75" Lg. 45 12323 index Plate
6 726-0188 Plastic Cable Tie 46 13407 —456 Chute Door
7 749-0393 Lower Handle N 47 10639 Pivot Brkt. Ass’y.—R.H.
8 714-0104 Hairpin Cotter 5/16" Dia. 48 712-0342 Hex Jam Nut 3/8-16 Thd.
9 710-0353 Slotted Oval Hd. Self-Tap 49 736-0105 Belleville Wash. 3/8" I.D.
Scr. 50 736-0219 Belleville Wash. .440 I.D.
10 731-0408 Rear Control Cover 51 732-0346 Torsion Spring
11 731-0406 Lever—Clutch Control 52 738-0386 Hinge Pin .250" Dia. x 7.25"
12 731-0407 Front Control Cover Lg-
13 746-0308 Clutch Control Cable 58" Lq. 53 710-0654 Hex Wash. Hd. Self-Tap Scr.
14
—
Engine 3/8-16
X
.88" Lg. N
15 13773 —452 Engine Mount Cover Plate 54 710-0258 Hex Bolt
1
/
4 - 2 0 X
.62" Lg.*
16 712-0287 Hex Nut 1/4-20 Thd.* 55 736-0211 FI-Wash. .285" I.D. x 1.25"
17 736-0329 L-Wash.
1
/
4
" I.D.* O.D.
X
.060 Thk.
18 710-0642 Hex Wash. Hd. Self-Tap Scr. 56 731-0449 Rear Flap Ass’y. N
1
/
4 - 2 0 X
.75" Lg. 57 14012 —456 Grass Catcher Hitch Brkt.
19 12321 Height Adj. Ass’y-—L.H. 58 710-0703 Carriage Bolt V4-20 x .75"
12322 Height Adj. Ass’y.—R.H. Lg.*
(Not Shown) 59 731-0430 Plastic Roller
20 734-0894 Wheel Ass’y. Comp.—Front 60 736-0185 FI-Wash. .406" I.D.
X
.74"
8.0
X
1.75 O.D.
X
.063
21 14005 —456 22" Deck Ass’y. N 61 710-0776 Hex Wash. Hd. Self-Tap Scr.
122 712-0297 Oval Nut 3/8-16 Thd. (Special) 1
/
4 - 2 0 X
.62" Lg. N
23 13406 —456 Rear Chute—R.H. 62 736-0329 L-Wash.
1
/
4
" I.D.*
24 710-0167 Carriage Bolt
1
/
4
-20 x .50" 63 714-0507 Cotter Pin 3/32" Dia. x .75"
Lg,* Lg.*
25 10769 Blade Adapter Kit 64 12296 Handle Mount Brkt. Ass’y.—
26 714-0365 #6 Hi-Pro Key 5/32 x 5/8" Dia. R.H.
27 10769 Blade Adapter Kit | 65 12297 Handle Mount Brkt. Ass’y.—
28 736-0217 L-Wash. 3/8" I.D. Heavy Duty L.H.
29 710-0459 Hex Bolt 3/8-24
X
1.50" Lg. 66 13924 Grass Catcher—Lower
(Grade 5) Frame Ass’y.
30 710-0117 Hex Bolt 5/16-24 x 1.00" Lg. 67 712-0267 Hex Nut 5/16-18 Thd.*
(Grade 5) 68 736-0119 L-Wash. 5/16" I.D.*
31 742-0125 22" Blade 69 13435 Cam—Lever Grip Ass’y.
32 736-0119 L-Wash. 5/16" I.D.* 70 738-0140 Shid. Bolt .437" Dia. x .180"
33 712-0123 Hex Nut 5/16-24 Thd.* Lg.
34 14014 —456 Rear Chutq Baffle—L.H. N 71 749-0278 Grass Catcher Upper Frame
35 738-0430 Shid. Bolt .50" Dia. x .685" 72 764-0171 Grass Bag
Lg-
73 09966 Hand Knob
36 726-0106 Push Nut
1
/
4
" Rod 74 749-0376 Upper Handle N
37 710-0209 Hex Sems Bolt 3/8-16 x .62" 75 726-0134 Speed Nut #8-32 Twin Type
Lg.* 76 746-0375 Conduit and Wire N
38 736-0105 Belleville Wash. 3/8" I.D. 77 731-0344 Plastic Cover
39 741-0262 Plastic Flange Bearing 78 738-0269 Shid. Bolt.
*For faster service obtain standard nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part
number and size as shown on parts list.
(456—Radiant Tangerine)
When ordering parts, if color or finish is important use the
appropriate color code shown above, (e.g. Radiant Tangerine
Finish —14005 (456).)
NOTE: The engine is not under warranty by
the mower manufacturer... If repairs or
service is needed on the engine, please
contact your nearest author- /i'-;— n /—■
ized engine service outlet. Fif'd I* Fsst
Check the “Yellow Pages” of In The
your telephone book under Yellow Pages
“Engines—Gasoline.”
