_________________ REPAIR PARTS LIST — CONTROL BOX
Drawing No. 83699
ITEM
PART NO.
QTY.
DESCRIPTION
1
23484-F
2
SB-1000-12 Snap Bushing
2
32300
1
30-amp AGC Fuse Hoider
3
81904
1
14-amp SFE Fues Holder
4
22668
1
30-amp AGC Fuse
5
55927
1
14-amp SFE Fuse
6
75207-B
1
10-amp DC Circuit Breaker
7
22220
1
No. 6
X
7/8" long Round Head Machine Screw
8
22155
1
No. 6 Lock Washer
9
25433
1
No. 6-No. 14 AWG Solderless Lug
10
39271
1
3/4" Greenlee, 90-degree Conduit Clamp
11
48512
1
5-amp Circuit Breaker
12
81903
1
Control Box
13
71938-A
1
DC Regulator
14
67680
1
AC Regulator Assembly
15
83635
1
AC Transformer
16
74969
1
35-amp Circuit Breaker
17
36900
4
No. 6-32
X
1/4" Phillips Pan Head Machine Screw
18
22155
4
No. 6 Lock Washer
19
23762
1
No. 10 External Lock Washer
20
81902
1
Control Panel
21
81884-D
1
Control Pane! Decal
22
74076
2
M3-0.5
X
10mm Pan Head Machine Screw
23
77604
1
Hour Meter
24
75208
1
Start/Stop Switch
25
55920
1
Preheat Switch
26
42568
2
M6-1.0
X
20mm Hex Head Capscrew
27
26850
2
M6 External Lock Washer
28
22152
10
M5 Lock Washer
29
23897
8
M5 Flat Washer
30
45770
8
M5-0.8
X
10mm Hex Head Capscrew
31
*77744
1
Customer Leads
32
74041
1
M5-0.8
X
20mm Phillips Pan Head Machine Screw
33
51718
2
M4-0.7
X
10mm Pan Head Machine Screw
34
43184
2
M4 Lock Washer
35
51715
2
M4-0.7 Hex Nut
36
80882
4
No. 6
X
5/8" Self-tapping Screw
37
72566
4
Spacer Nut
39
70325
1
Engine Controller Assembly
40
22097
6
M6 Lock Washer
41
51716
2
M5 Hex Nut
42
55440
2
M5-0.8
X
25mm Hex Head Capscrew
44
*82617
1
Panel Wire Harness
45
*81951
1
Engine Wire Harness
46
82737
4
Vibration Dampener
47
49813
4
M6-1.0 Nut
48
22188
1
No. 6 Hex Nut
49
22473
8
M6 Flat Washer
NOT SHOWN
