REPAIR PARTS — GASOLINE ENGINE SHEET METAL
Drawing No. A9194
ITEM
PART NO.
QTY.
1
86705
1
2
49813
2
3
86718
3.5 ft.
4
A3666
1
5
74908
31
6
A3667
2
7
22129
12
8
39414
4
12
89680
1
13
94670
1
17
89471
1
18
86731A
1
19
86715
1
20
86726
1
21
86671
1
22
86727
1
23
86719
1
24
20519
1
25
90141A
1
26
86724
1
27
90475
1
28
28740
1
29
22127
3
30
22097
7
31
86729
1
32
90518
1
33
89048
1
34
90537
1
35
22145
4
36
30340
1
37
48031C
5
38
23484D
1
39
23762
2
40
22471
2
41 '
22264
2
42
79246
2
44
22447
3
DESCRIPTION
PLATE. DIVIDER
M6-1.0HEX NUT
SEAL RUBBER EXTRUSION
WRAPPER. BOX
TAPTITE. M5- .8 X10 LONG
MOUNTING RAILS
M8 LOCK WASHER
M8-1.25X35MM CAPSCR.
SPARK ARRESTOR
U-BOLT. W/SADDLE & NUTS
DEFLECTOR. AIR OUT
ASSEMBLY. MUFFLER
HOUSING. LOWER FAN
SKIRT. CARB. BAFFLE
COVER. ROCKER COVER
SKIRT. SPARK PLUG SIDE
PAN.BELLY
FRAME
GROUND STRAP
PLATE. BASE COVER
PUMP. FUEL
BARBED 90 1/8"
X
1/4"
HEX NUT. 1/4”-20
LOCKWASHER-1/47M6
CONTACTOR. STARTER
BOOT. CONTACTOR
SEAL. OIL FILTER HOLE
RETAINER. SEAL
M8 FLAT WASHER
1/4” FUEL LINE-4“ LONG
1/4* HOSE CLAMP
SNAP BUSHING
EXTERNAL SHAKEPROOF
#8 HEX NUT
#8 LOCK WASHER
CAPSCR.. M6-1.0 X16 LONG
W/LOCKWASHER
WASHER. INTERNAL
SHAKEPROOF. 1/4“/M6
TEM
PART NO.
QTY.
DESCRIPTION
45
103-74260
1
GROUND STRAP. UNIT
47
39450
1
1/8”x3/16”NPT90 DEG.
BARBED FITTING
48
92000
1
BRACKET. MUFFLER
HANGER
49
30340
1
1/4" FUEL LINE (8" LONG)
50
82580D
1
3/16" CARBURETOR LINE
(4" LONG)
51
86311
1
FUEL FILTER
53 007-91297
1
STARTER CONTACTOR
GROUND WIRE
54
89045
1
SEAL. WASHER EXHAUST
PIPE
57
A3638
1
PANEL. WRAPPER BOX
59
56893
11
CRIMPTITE. #10-24x1/2“
60
A5767
1
HEX HD. CAPSCR..
M5-0.8
X
6 LONG
61
A3764
2
CUSTOMER MOUNTING
BRACKET
62
66443B
4
VIBRATION MOUNT
63
20668
2
EARTHING STRAP
64
45771
8
HEX NUT-M8
65
38353
3
VIBRATION MOUNT
67
79119
2
TAPTITE 1/4”-20
68
A7213
2
TAG. REMOVE BOLT
69
23897
4
FLAT WASHER #10/M5
70
A9172
1
BRACKET. IGNITION SYS.
71
89047
2
SPACER. IGNITION COIL
72
86711
1
MODULE. IGNITION
73
89049B
1
ASSY.. IGNITION COIL
74
49721
2
M6-1.0X35MM HEX
HD. CAPSCREW -
75
49813
4
M6-1.0 HEX NUT
76
91526
2
M5-0.8X12MM PHILLIPS
PAN HD. MACH. SCREW
77
51716
2
M5-0.8 HEX NUT
78
49226
2
LOCK WASHER. M5
79
84867
2.5 FT.
RUBBER “U” CHANNEL
80
56892
1
CRIMPTITE #10-24X3/8”
— 51
