__________ REPAIR PARTS — LP ENGINE SHEET METAL
Drawing No. A9193
ITEM
PART NO.
QTY. DESCRIPTION
ITEM
PART NO. QTY.
DESCRIPTION
1
86705
1
PLATE, DIVIDER
45
74260-103
1
GROUND STRAP, UNIT
2
56893
11
CRIMPTITE 10-24x1/2“
47
47290
1
HOSE-3/8 I.D.
X
11-1/2" LONG
3
86718
3.5FT.SEAL RUBBER EXTRUSION
48
92000
1
BRACKET, MUFF. HANGER
4
A3666
1
BOX, WRAPPER
49
25425
2
STREET ELB. 45 « 3/4“ NPT
5
74908
30
TAPTITE, M5- . 8 x 1 0 LONG
50
26490
1
PIPE NIPPLE 3/4“
X
2"
6
A3667
2
MOUNTING RAILS
51
94670
2
“U“ BOLT W/SADDLE & 2-NUTS
7
22129
12
M8 LOCK WASHER
53
91297-007
1
STARTER CONTACTOR
8
39414
4
M8-1.25X35MM CAPSCR.
GROUND WIRE
10
75494
2
SELF DRILL. SCREW
54
89045
1
SEAL, WASHER EXHAUST
#10-16X5/8"
PIPE
11
A3638
1
WRAPPER, END PANEL
55
A2666
1
FUEL SOLENOID 12VDC
12
89680
1
SPARK ARRESTER
57
22145
2
5/16“ FLAT WASHER
17
89471
1
DEFLECTOR, AIR OUT
58
A4603
1
BRACKET L/P
18
86731A
1
ASSEMBLY, MUFFLER
59
22507
2
CAPSCR., HEX HD.-
19
86715
1
HOUSING, LOWER FAN
1/4”-20x1/2”LG
20
86726
1
SKIRT, CARB. BAFFLE
60
A5606
1
LP HOOK-UP FITTING
21
86671
1
COVER, ROCKER COVER
61
A3764
2
CUSTOMER MOUNTING
22
86727
1
SKIRT, SPARK PLUG SIDE
BRACKET
23
86719
1
PAN, BELLY
62
66443B
4
VIBRATION MOUNT
24
20519
1
FRAME
63
20668
2
EARTHING STRAP
25
90141A
1
GROUND STRAP
64
45771
8
HEX NUT-M8
26
86724
1
PLATE, BASE COVER
65
38353
3
VIBRATION MOUNT
27
43790
1
90 « BARB. FITG. 3/8“ x 3/8" NPT
66
56892
1
CRIMPTITE #10-24X3/8
29
22127
5
HEX NUT, 1/4"-20
67
79119
2
1/4”-20 TAPTITE
30
22097
9
LOCK WASHER-1/4"/M6
68
A7213
2
TAG, BOLT REMOVAL
31
86729
1
CONTACTOR, STARTER
69
A5767
1
HHCS M5-0.8 X 6MM
32
90518
1
BOOT, CONTACTOR
70
A9172
1
BRACKET, IGNITION SYSTEM
33
89048
1
SEAL, OIL FILTER HOLE
71
89047
2
SPACER, IGNITION COIL
34
90537
1
RETAINER, SEAL
72
86711
1
MODULE, IGNITION
35
22145
4
FLAT WASHER-M8
73
89049
1
ASSY., IGNITION COIL
36
75211
1
REGULATOR
74
49721
2
M6-1.0X35MM HEX HD.
37
40173
1
HOSE CLAMP
CAPSCREW
38
23484D
1
SNAP BUSHING
75
49813
4
M6-1.0 HEX NUT
39
23762
2
EXT. SHAKEPROOF-#10
76
91526
2
M5-0.8X12MM PHILLIPS
40
22471
2
#8-32 HEX NUT
PAN HD. MACH. SCREW
41
22264
2
#8 LOCK WASHER
77
51716
2
M5-0.8 HEX NUT
42
79246
2
CAPSCR., M6-1.0X 16LG-
78
49226
2
LOCK WASHER, M5
W/LOCK WASHER
79
84867
2.5'" RUBBER “U" CHANNEL
43
23897
4
FLAT WASHER #10/M5
80
56892
1
CRIMPTITE #10-24 X 3/8"
44
22447
3
WASHER, INTERNAL SHAKE
PROOF, 1/4“/M6
49 —
