REPAIR PARTS — LP GENERATOR
Drawing No. A6413
ITEM
PART NO.
QTY. DESCRIPTION
ITEM
PART NO.
QTY, DESCRIPTION
1
A2467
1
ENGINE, LONG BLOCK
57
42907
3
CAPSCR., M8-1.25
X
16 LONG
2
94583
1
FLYWHEEL, FAN
58
22129
10 LOCKWASHER-M8
3
83312
2
WASHER, CONICAL
59
74906
4
CAPSCR., M6-1 X20LG. TAPTITE
4
81810
2
HEX NUT, Ml6-1.5
61
39253
3
CAPSCR., M8-1.25 x 20 LONG
5
70185
1
FILTER, OIL
62
22511
3
CAPSCR., 3/8"-16
X
1.25" LONG
6
86730
1
TUBE, EXHAUST OUTLET
63
22237
3
LOCKWASHER-3/8"
7
89476
1
GASKET, EXHAUST
64
55822
2
PHMS, M4-0.7
X
8 LONG
8
40976
4
CAPSCR., M8-1.25x20 LG.
65
22264
2
LOCKWASHER-M4
9
99948
1
STARTER MOTOR
66
&..050
2
PHILUPS PAN HD. MACH. SCREW-
11
86705
1
PLATE, DIVIDER
M6-1
X
90 LONG
12
22097
9
LOCKWASHER, 1/4"-M6
67
82774
1
WOODRUFF KEY-4
X
19
14
92059
1
STEPPER MOTOR
68
59637
4
TAPTITE 3/8"-16
X
.75 LONG
15
86706
1
ROD, THROTTLE CONTROL
69
86697
1
ASSEMBLY IGNITION SENSOR
16
89477
1
CLIP, ADJUSTMENT
70
86704
3
SPACER, ENGINE MOUNT
17
89478
1
SNAP, RETAINING
71
86701
1
BRACKET, ENGINE MOUNT FR
18
90192
1
WASHER, CARBURETOR
72
86702
1
BRACKET, ENGINE MOUNT RR
19
A2774A
1
CARBURETOR ASSEMBLY
73
38353
3
RUBBER MOUNTS
20
90051
2
GASKET, CARB./SPACER/HEAD 74
89263
1
ASSEMBLY, OIL FILL CAP
21
78631
1
GASKET, CARBURETOR/SKIRT
75
90071
1
O-RING, 1.062" I.D.
22
96459
1
GASKET, CARB./INLET ADAPT.
76
94637
1
OIL FILL TUBE
23
86709
1
ADAPTOR, CARB. INLET
77
90072
1
0-RING .562" I.D.
24
35586
2
HOSE CLAMP-BAND 1.25"
78
86708
1
CARBURETOR SPACER
25
86710
1
HOSE, CARBURETOR INLET
79
87478
1
GASKET, OIL FILTER ADAPTOR
26
87993
1
ELBOW, AIR CLEANER OUTLET 80
96627
1
BRACKET, START SIDE ENG MNT.
27
49815
2
HEX HD. CAPSCR., M5-.8 x 16
81
90613
1
COVER, BREATHER CANAL
28
90536
1
GASKET, AIR CLEANER OUT.
82
59635
1
NO. 8
X
3/8" PLASTITE SCREW
29
90021
1
BRACKET, AIR CLEANER SUPP. 83
002-91297
1
STARTER WIRE
30
94665
1
HOUSING, FAN-UPPER
85
59636
1
PLASTITE SCREW, #4 x .37 LG
31
93859
1
FAN, GENERATOR
86
88905
1
EXTENSION SPRING
32
A5892
1
ASSEMBLY, MAGNET HOUSING 87
92800
1
WRAPPER, ENGINE TOP
35
86673
1
BASE, AIR BOX
88
89062
1
HOSE, BREATHER
36
78601
1
ELEMENT, AIR FILTER
91
22447
3
WASH., INT. SHAKEPROOF, 25"
37
86674
1
COVER, AIR BOX
96
23897
5
#10-M5 FLAT WASHER
38
78609
2
BOLT, AIR CLEANER COVER
97
94090
1
SWITCH, THERMAL OIL TEMP.
39
66449C
4
HEX HD. CAPSCR., M6-1 x 80
99
86675A
1
ADAPTOR, OIL FILTER
40
49226
6
LOCKWASHER, M5
100
77667
1
4 PSI OIL PRESSURE SWITCH
41
80934
1
RETAINING RING, STATOR
101
86714
1
SCREEN, OIL PICK-UP
42
A6420
1
ASSEMBLY STATOR
102
52617
1
DRAIN PLUG, Ml2
X
1.75" LONG
43
86692
1
ADAPTOR. STATOR
103
94643
1
GASKET, OIL DRAIN PLUG
44
74908
3
TAPTITE, M5-0.8X 10
104
74027
2
SCREW, M3
X
5“ LONG
45
57822
1
CLAMP, HOSE
105
43182
2
LOCK WASHER-M3
53
45756
3
M6-1
X
10 TAPTITE
106
A1643
1
A/C DECAL
54
83512
1
TAPTITE M8-1.25 x 15 LONG
107
92079
4
TAPTITE, M6-1
X
25 LONG
55 '
91526
4
CAPSCR., M5-0.8XM12
108
86726
1
SKIRT, BAFFLE
