OPTIONAL ACCESSORIES
A plug-in receptacle (Figure 36) is provided on the
generator set, near the DC power wires. Use this
receptacle
to
connect
an
optional
remote-mounted
start/stop panel to the generator. Installation of such a
panel will permit you to start and stop the generator
engine from any convenient location inside the vehicle.
Figure 36 — Remote Panel Plug-In Receptacle
Model 9043: This panel mounts a rocker type switch, a
“Generator Run” lamp and an hourmeter (Figure 38).
Use the hourmeter in conjunction with the periodic
maintenance schedule for your generator.
Figure 38 — Model 9043 Remote Panel
o
o
GENERAC R.V. GENERATOR
REMOTE PANEL MODELS
Model 9042: This remote panel (Figure 37) mounts a
rocker type start/stop switch and a “Generator Run”
advisory lamp. The lamp will turn on to indicate the
engine is running.
Figure 37 — Model 9042 Remote Panel
REMOTE PANEL CABLES
Interconnection cables are available from Generac for
connecting the optional remote panels to the generator
receptacle.
• To order a 10-foot long, 4-wire cable, specify Model 9045.
• To order a 30-foot long, 4-wire cable, specify Model 9046.
©
