Models 800,
860 and 960
PARTS LIST FOR MODELS 800, 860 AND 960
SNOW THROWERS
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
710-0600
Hex Wash. Self-Tap Scr.
31
712-0116
Hex Ins. Jam L-Nut 3/8-24
5/16-24
X
.50" Lg.
Thd.
2
731-0321
Belt Cover
32
756-0240
Fl-ldler w/Flanges 3.0 O.D.
3
714-0118
Sq. Key V4"
X
1.50" Lg.
33
05531
Brake Linkage Ass’y.
4
---'
Engine
34
712-0116
Hex Ins. Jam L-Nut 3/8-24
5
712-0267
Hex Nut 5/16-18 Thd.*
Thd.
6
736-0119
L-Wash. 5/16" Scr.*
35
756-0240
3.0" O.D. Fl-ldler w/Flanges
7
717-0522
Engine Spacer Ass’y.
(800)
(Used w/Tech. Engine)
756-0225
Flat Idler Pulley (860 & 960)
8
736-0105
Bell-Wash. .40 I.D. x .88
36
714-0104
Int. Cot. Pin 5/16" Dia.
O.D.
37
738-0282
Shid. Scr. .625 Dia. x 2.750"
9
738-0215
Shid. Scr. .498" Dia. x 3.00"
Lg.
Lg. (800)
38
750-0227
Spacer .75 O.D. x 1.00" Lg.
711-0769
Stud 3/8-16
X
3.37" Lg.
39
05493
Blower Idler Brkt. Ass’y.
(860 & 960)
40
747-0149
Auger Clutch Rod .31" Dia. x
10
732-0303
Ext. Spring .38 O.D. x 3.18"
10.62" Lg.
Lg.
41
710-0191
Hex Bolt 3/8-24 x 1.25" Lg.
11
712-0375
Hex Cent. L-Nut 3/8-16 Thd.
42
736-0217
L-Wash. 3/8" Scr. H.D.
12
05491
—452
Engine Brkt. Ass’y-'
43
07386
FI-Wash.
13
710-0198
Hex Sems Scr. 5/16-18 x
44
756-0241
Engine Pulley—Double
.75" Lg.*
Groove (800)
14
05487
—452
Frame Ass’y.
756-0429
Engine Pulley (860 & 960)
15
736-0264
FI-Wash. .345 I.D. x .75 O.D.
45
754-0131
“V”-Belt 3/8
X
35.5 Lg.
X
.060
46
710-0237
Hex Scr. 5/16-24
X
.62" Lg.*
16
710-0378
Hex Scr. 5/16-18 x 2.50" Lg.*
47
736-0242
Bell-Wash. .345 I.D. x .88
17
736-0217
L-Wash. 3/8" Scr. H.D.
O.D.
X
.060
18
710-0555
Pilot Scr. 3/8-16
X
.88" Lg.
48
05495
Drive Idler Brkt. Ass’y.
19
736-0119
L-Wash. 5/16" Scr.*
49
738-0281
Shid. Scr.—.625" Dia. x .170"
20
712-0267
Hex Nut 5/16-18 Thd.*
Lg.
21
712-0798
Hex Nut 3/8-16 Thd.*
50
736-0219
Bell-Wash. .40 I.D. x 1.12
22
736-0217
L-Wash. 3/8" Scr. H.D.
O.D.
23
738-0143
ShId. Scr. .498" Dia. x .340"
51
736-0264
FI-Wash. .34 I.D. x .750 O.D.
Lg.
X
.05
24
756-0344
V-Pulley .628 I.D.
X
7.50 O.D.
52
737-0130
Pipe Nipple—Vz" Pipe Thd.
25
736-0158
L-Wash. for 5/8" Scr.*
X
3.00" Lg.
26
712-0221
Hex Ins. Jam L-Nut 5/8-18
53
737-0132
Hex Scr. 1/4-18 Pipe Thd.
Thd.
54
736-0264
FI-Wash. .340 I.D. x .62 O.D.
27
05510
Brake Brkt. Ass’y.
X
.62
28
738-0129
Shid. Scr. .498" Dia. x 2.00"
55
751-0360
Throttle Control Wire Clamp
Lg.
56
710-0899
Hex Sems Scr. #10-32 x .62"
29
756-0243
V-Pulley .875 I.D. x 10.12 O.D.
Lg.
30
754-0194
“V”-Belt Vz"
X
45.0" Lg.
725-0954
Ignition Key (Not Shown)
*For faster service obtain standard nuts, boits and washers
iocally. if these items cannot be obtained locaily, order by
part number and size as shown on parts iist.
(488—Mack Truck Yellow)
When ordering parts, if coior or finish is important use the ap
propriate coior code shown above, (e.g. Mack Truck Yeliow
Finish—05487 (488).)
The engine is not under warranty by the snow thrower manufacturer. If repairs or service is needed
on the engine, piease contact your nearest authorized engine service outiet. Check the “Yeilow
Pages” of your teiephone book under “Engines—Gasoiine.”
