When cleaning is complete and needle is still in its highest position, replace as follows :
1. Place shuttle A Fig. 71 against driver D and adjust into position.
2.
Replace race cover B, fitting pin at lower edge into notch, and lock into position with clamps
C making certain the clamps have snapped securely into place.
3.
Put the bobbin case into position by fitting tongue into groove of race cover.
HOW TO OIL YOUR MACHINE
For a free and easy running machine proper oiling is of the utmost importance and essential
that you use White Sewing Machine oil for for this purpose.
When in continuous use the machine should be oiled every day. For moderate use an
occasional oiling is satisfactory.
To reach the parts inside the arm remove the two
screws holding the top cover and remove it.
Apply only a drop of oil to the parts indicated
by the arrows in Fig. 72. Now turn the hand wheel
and apply a drop of oil to all moving parts. After
oiling moving parts replace top cover.
The face plate opens sideways on hinges making
oiling and cleaning easy. See Fig. 73, Oil all mov
ing parts.
Fig. 72
