Getting to Know Your Machine
principal parts-
I.Hand Wheel
9. Bobbin Winder Tension
2. Bobbin Winder
10. Take-up Lever
3. Spool Holder
11. Thread Guides
4. Stitch Pattern Selector
(only 8019)
12. Built-in Sewing Light
13. Thread Cutter
5. Pattern Group Selector
14. Presser Foot
(only 8007 and 8019)
6. Stitch Width Selector
15. Zig-Zag Needle Plate
7. Snap-in Thread Guide
16. Slide Plate
8. Tension Dial
17. Needle Clamp
