SINGER 14U52 - Manual (Page 26)

Left looper thread wrapped rolled hem stitching (rolled hem variation).
Correct thread tension
A beautiful seam can be obtained on hard-to-roll light­
weight fabrics by this method of stitching.
Tension Dial
Blue Green Orange Yellow
2.0 Spreader 1.5
Make minor adjustments to obtain even better thread tensions.
When needle thread is too loose or left When left looper thread is too loose ^
looper thread is too tight
I
Needle thread \
Needle thread \
Left looper
Left looper thread
thread
Topside
Topside Underside
Underside
Turn needle thread tension dial (green) in Turn left looper thread tension dial (yellow)
the (+) direction or left looper thread tension in the (+) direction.
dial (yellow) in the (—) direction.
4. How to sew
Sewing
• Refer to “Chain off and test sew”on page 9.
• For rolled hemming, a better stitch quality can be obtained by pulling the fabric lightly in the
forward direction to give slight tension to the fabric.
• When starting to sew, hold chained off thread end lightly to prevent it from being sewn into the
seam.
• The minimum overedge seam width that can be obtained for rolled hem is approximately 1.5mm
because the cutting width can not be set below 3.5mm.
24
