SINGER W571 - Manual (Page 24)

:
23
‘3
’
M
QUILTING GUIDE. This guide for making pa­
rallel rows of stitching is attached by placing the
pronged holder between the presser foot and the
presser foot clamp screw (Fig. 33).
Adjust the curved bar to press lightly on the
fabric.
By letting the guide radio on the first stitching
line, successive rows will be an equal distance apart.
When the bar is attached so that the curved part
is to the right of the needle, it may also serve as a
seam width guide.
SEAM GAUGE OR CLOTH GUIDE. Use the
seam gauge as a guide for straight seams and even
rows of top stitching along edges of fabric. Fasten
gauge with accompanying screw in threaded hole in
needle plate or in bed of machine (Fig. 34). Adjust
to seam width desired.
Fig. 33
Fig. 34
