SINGER W167 User Manual
Page 5
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
FEATURES AND PARTS
(Front View)
1.
Spool Pins
13.
Presser Foot
2.
Stitch Width Lever i 1 /
14.
Needle Clamp and Screw
3.
Zigzag Stop Knobs
15.
Attachment and Foot Thumb Screw
4.
Hand Wheel
16.
Needle Bar Thread Guide
5.
Wheel Clutch
17.
Thread Guides
6.
Bobbin Winder
18.
Tension Regulator
1
7.
Stitch Length Dial
19.
Light Switch
I
8.
Reverse Push Button
20.
Take-up Lever
1
9.
Bobbin Winding Tension
21.
Pressure Release Darner
1
10.
Drop Feed Knob
22.
Arm Thread Guide
I
11.
Cover Plate
23.
Button hole Chance Lever ' < ,5
1
12.
Needle Plate-Seam Guide
24.
Pattern Selector Dial
