THREADING THE BOBBIN CASE
.VC7
1. Remove the extension table from the
machine by pulling it to the left
Open the shuttle cover by pulling
down the embossed part on the left
side of the cover.
2. Raise needle to its highest position
by rotating hand wheel toward you.
3. To remove bobbin case from shuttle,
pull open latch of bobbin case.
4. Pull bobbin case straight out
shuttle.
of
5.
Insert bobbin into bobbin case
making sure thread is coming from
bobbin as shown.
6. Pull thread through slot of case as
shown.
7. Pull thread under tension spring.
8. Holding latch open, position case
into shuttle, and release latch. Case
should lock into place when latch
is released.
14
.
