Place spool on spool pin as shown, with

thread coming from the back of the

spool.

Draw thread through top thread guides.

Holding

spool

stationary

with

right

hand, pull the end of the thread between

the tension discs as shown above (3).

Pull the end of the thread taut with left

hand. This will pull the spring wire up

and past the end of the hook. The

thread will then slip into the hook when

the spring is released as in (4i.

Release spool of thread and thread

machine through take-up lever (5) and
thread guide (6i as shown above. Thread

then passes through guides (7) and (8).

Thread needle (9) from front to rear.
